POWERSHIELD Defender Rackmount 800VA / 480W UPS ,Line Interative Simulated Sine Wave Perfect for Shallow Racks, Compact Model

larger image

Model: PSDR800
Shipping Weight: 13kgs
Manufactured by: POWERSHIELD

Login for price

Capacity 800VA / 480W
Topology Line Interative
INPUT
Voltage 240Vac (Nominal)
Voltage Range 177-290Vac
Frequency Range 50/60Hz (auto sensing)
OUTPUT
Output Voltage 240Vac 10%
Frequency Range (Batt. Mode) 50Hz or 60Hz Hz
Transfer Time 6ms (Typical)
Waveform (Batt. Mode) Simulated Sine Wave
Australian Outlets - UPS & Surge Protection 2x 10 Amp IEC Sockets, 6 x Australian Sockets
BATTERY
Battery Type & Number 12V / 9AH (x1)
Typical Recharge Time 4- 6 hours recover to 90% capacity
Backup Time (50% Load) 8 min
PROTECTION
Full Protection Overload, discharge and overcharge protection
Surge Protection 312Joules / 6500Amps
COMMUNICATIONS & MANAGEMENT
Interface USB interface
Software NetGuardsupports - WindowsLinux, Unix and Mac (Free Download)
LCD Alarm AC Mode, Battery Mode, Low Battery (Batt. Mode), Fault, Overload
Audible Alarm Battery Mode, Low Battery (Batt. Mode), Fault, Overload
PHYSICAL
Dimension L x W x H (mm) 230 x 438 x 86
Net Weight (kgs) 7.7
OPERATING ENVIRONMENT
Temperature 0-40C
Humidity 0-90% RH (non-condensing)
Noise Level Less than 5dBA @ 1 meter (no fan)
COMPLIANCE
Safety/EMC EN62040-1 -1 2003, IEC60950-1 : 2001, EN62040-2 2006
RoHS Directive 2011/65/EU
