Gigabyte Z390 I AORUS PRO WIFI LGA1151 9Gen mITX MB 2xDDR4 1xPCI

  • Model: GAZ390GAMINGSLI
  • Manufactured by: GIGABYTE

Login for pricing

Gigabyte Z390 I AORUS PRO WIFI LGA1151 9Gen mITX MB 2xDDR4 1xPCIe HDMI DP 2xM.2 4xSATA RAID Intel GbE LAN 2xUSB-C 7xUSB3.1 BT WiFi RGB

Intel Z390 AORUS Motherboard with 6 Phases Digital VRM solutions, Extended Heatsink, HDMI 2.0 & DisplayPort onboard, 802.11ac Wi-Fi, RGB Fusion, Dual M.2 with Single Thermal Guard, Front USB 3.1 Gen 1 Type-C, IntelGbE LAN with cFosSpeed

Supports 9th and 8th Gen IntelCoreProcessors
Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
IntelOptaneMemory Ready
6 Phases IR Digital VRM Solution with PowIRstage
Advanced Thermal Design with Extended Fin Heatsink
Onboard IntelCNVi 802.11ac 2x2 Wave 2 Wi-Fi
ALC1220-VB Enhance 114dB(Rear)/ 110dB(Front) SNR in Microphone with WIMA Audio Capacitors
IntelGigabit LAN with cFosSpeed
RGB FUSION with Multi-Zone Addressable LED Light Show Design, Supports Addressable LED & RGB LED Strips
Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
Front USB 3.1 Gen 1 Type-CHeader
Dual Ultra-Fast M.2 with PCIe Gen3 x4 interface, one with Thermal Guard
CEC 2019 Ready, Save Power With a Simple Click

CPU
Support for 9th and 8th Generation IntelCorei9 processors/IntelCorei7 processors/IntelCorei5 processors/IntelCorei3 processors/IntelPentiumprocessors/IntelCeleronprocessors in the LGA1151 package
L3 cache varies with CPU
(Please refer "CPU Support List" for more information.)
Chipset
IntelZ390 Express Chipset
Memory
2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
Dual channel memory architecture
Support for DDR4 2666/2400/2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
(Please refer "Memory Support List" for more information.)
Onboard Graphics Integrated Graphics Processor+MegaChips MCDP2800 chip:
1 x HDMI port
